Industrial Coating
UVICHEM 520 is a UV-curing paint for tiles that mainly consists of UV-curing oligomer and monomer. It features outstanding adhesiveness, scratch resistance, crack resistance, and contamination resistance.
specification
- Paint type
- UV-curable paint
- Product features
- 1. UV-curing coating agent featuring low yellowing effect 2. After curing, it offers outstanding elasticity due to its flexible film as well as superior scratch resistance. 3. Eco-friendly paint featuring outstanding adhesiveness for PVC surfaces 4. This high rigidity paint features outstanding wear resistance and exterior look.
- Exterior
- Semi-transparent liquid
- UV-curing conditions
- 700 - 800 mJ/㎠
- Specific gravity (25 ℃)
- 1.18 ± 0.05
- Viscosity (PO/30 ℃)
- 800 - 1200
- Coverage (g/㎡)
- 20 - 25
- Solid content (%)
- Above 99
- Color
- Transparent
- Shelf life
- 12 months
- Mixing ratio
- One-component
- Thinner
- No dilution
how to use
- Surface treatment
- 1. Substrate processing Substrate processing Substrate processing Substrate processing Substrate processing Substrate processing Substrate processing
Completely remove oil, moisture, sand, dust and foreign substances from the surface. Remove oil, moisture, sand, dust, and other foreign substances on the surface to be painted completely. Remove oil, moisture, sand, dust, and other foreign substances on the surface to be painted completely. Remove oil, moisture, sand, dust, and other foreign substances on the surface to be painted completely. Remove oil, moisture, sand, dust, and other foreign substances on the surface to be painted completely. Remove oil, moisture, sand, dust, and other foreign substances on the surface to be painted completely. Remove oil, moisture, sand, dust, and other foreign substances on the surface to be painted completely.
Remove dust and static electricity using an air shower and an ionizer if necessary.
Residual contaminants may result in defective film exterior and adhesion. - Coating method
- Coating method
Paint using a roll coater or gravure coater.
There may be deviations in the application amount and gloss depending on working conditions (roll speed, work site temperature).
Avoid flammables during and after painting and perform sufficient ventilation.
Drying method
Dry it by passing it through a UV lamp. 700 mJ/㎠ or above recommended.
Dry it by passing it through a UV lamp. 300 - 400 mJ/㎠ or above recommended
There may be deviations in drying and gloss depending on the light intensity of a UV lamp.
