- UV-curable paint for PVC and PET films
- 21. UVICHEM 7600.pdf
UVICHEM 7600 is a UV-curing paint for films that mainly consists of UV-curing oligomer and monomer. It features outstanding adhesiveness, scratch resistance, crack resistance, and contamination resistance.
- Paint type
- UV-curable paint
- Product features
- 1. UV-curing coating agent featuring low yellowing effect 2. After curing, it offers outstanding elasticity due to its flexible film as well as superior scratch resistance. 3. Eco-friendly paint featuring outstanding adhesiveness for plastics, rubber, PVC surface, etc. 4. It features outstanding exterior look, high glossy, and chemical resistance.
- Semi-transparent liquid
- UV-curing conditions
- 700 - 800 mJ/㎠
- Specific gravity (25 ℃)
- 1.10 ± 0.05
- Viscosity (KU/25 ℃)
- 75 - 80
- Coverage (g/㎡)
- 5 - 10
- Solid content (%)
- Above 99
- Shelf life
- 12 months
- Mixing ratio
- Dilute it by selecting and using a solvent according to the process.
how to use
- Surface treatment
- 1. Substrate processing
Completely remove oil, moisture, sand, dust and foreign substances from the surface.
Remove dust and static electricity using an air shower and an ionizer if necessary.
Residual contaminants may result in defective film exterior and adhesion.
- Coating method
- Coating method
Paint using a roll coater or gravure coater.
There may be deviations in the application amount and gloss depending on working conditions (roll speed, work site temperature).
Avoid flammables during and after painting and perform sufficient ventilation.
Dry it by passing it through a UV lamp. 700 mJ/㎠ or above recommended.
There may be deviations in drying and gloss depending on the light intensity of a UV lamp.
